Zebra ZD600 series · Premium
ZD611 / ZD621
Premium 2- and 4-inch desktop printers with premium features, top performance and strong security, easy to deploy and manage with Print DNA.
The ZD611 replaces the ZD410d and TLP2824 Plus; the ZD621 replaces the GX Series, ZD500 and ZD620 Series. Ethernet, USB and USB Host are standard, and dual-radio Wi-Fi and Bluetooth can be added at the factory or in the field. The linerless models are part of the ZeroLiner solution; with no liner they deliver up to 50% more labels per roll and less waste.
Variants
- ZD611 DT: 2-inch, direct thermal; 5 status icons + 3 buttons; 220 x 115 x 151 mm (L x W x H), 1.07 kg.
- ZD611 Linerless Direct Thermal: 2-inch, for linerless labels; linerless platen, linerless cutter and label-taken sensor; tested with Zebra ZeroLiner labels.
- ZD611 TT: 2-inch, thermal transfer; 4.3-inch colour touch LCD standard; 74 m ribbon, width 33–58 mm; 242.9 x 138.7 x 169.2 mm, 1.629 kg.
- ZD621 DT: 4-inch, direct thermal; 221 x 177 x 151 mm, 1.6 kg.
- ZD621 Linerless Direct Thermal: 4-inch, for linerless labels; linerless platen, label-taken sensor and linerless cutter; optional 4.3-inch touch display.
- ZD621 TT: 4-inch, thermal transfer; 300 m or 74 m ribbon, width 33.8–109.2 mm; 267 x 202 x 192 mm, 2.5 kg.
- Serial port is standard on ZD621 models and field-installable on the ZD611.
- Print method
- Direct thermal or thermal transfer (by model); linerless models direct thermal only
- Resolution
- 203 dpi; optional 300 dpi
- Print speed
- Up to 203 mm/s (8 ips, 203 dpi) and 152 mm/s (6 ips, 300 dpi)
- Print width
- ZD611: 56 mm (203 dpi) / 54 mm (300 dpi); ZD621: 104 mm (203 dpi) / 108 mm (300 dpi)
- Media
- Width ZD611 15–60 mm, ZD621 DT 15–108 mm, ZD621 TT 15–118 mm; label length 6.35–991 mm; thickness ZD611 0.06–0.19 mm, ZD621 0.08–0.19 mm; roll OD up to 127 mm; core 12.7 and 25.4 mm (38.1, 50.8, 76.2 mm with adapters)
- Ribbon
- ZD611 TT: 74 m, width 33–58 mm; ZD621 TT: 300 m or 74 m, width 33.8–109.2 mm
- Connectivity
- Standard Ethernet, USB 2.0, USB Host, BLE 5 for setup (serial on ZD621); factory Wi-Fi 6 + Bluetooth 5.3 (MIMO); field Wi-Fi 6 + Bluetooth 5.3 (SISO); factory or field Wi-Fi 5 + Bluetooth 4.2, serial RS-232 for ZD611
- Printer languages
- ZPL II, EPL 2, XML, ZBI, PDF Direct
- Memory
- 512 MB flash, 256 MB SDRAM; real-time clock
- Options
- Dispenser/peeler with label-present sensor and cutter (factory or field); linerless (with Zebra ZeroLiner labels, direct thermal only, with cutter or peeler); 4.3-inch colour touch LCD (standard on ZD611 TT)
- Operating temperature
- 4.4 °C to 41 °C
- Dimensions and weight
- ZD611 DT: 220 x 115 x 151 mm, 1.07 kg; ZD611 TT: 242.9 x 138.7 x 169.2 mm, 1.629 kg; ZD621 DT: 221 x 177 x 151 mm, 1.6 kg; ZD621 TT: 267 x 202 x 192 mm, 2.5 kg
- Warranty
- At least 2 years (varies by region)
- Accessories
- 2,750 mAh battery, carrying case, ZKDU, mounting adapter bracket (to replace LP/TLP2824 Plus), enclosed power supply for ZD621
More views
Pricing
For enterprise hardware, price depends on quantity, configuration and service package. Add it to your quote list and we'll price it the same business day.
Use cases
- Shelf, markdown and information labels in retail
- Food safety and deli labels
- Pharmacy and prescription labels
- Specimen, lab and patient wristband labels in healthcare
- Ticketing and event wristbands in hospitality
- Document and evidence tracking in government
- Reducing waste with linerless labels
Not the right fit for
- Thermal transfer printing or non-ZeroLiner media on the linerless models: they print direct thermal only and work with ZeroLiner labels.
- Environments below 4.4 °C or above 41 °C: they fall outside the operating temperature range.
- Media wider than 118 mm: the limit is 118 mm on the ZD621 and 60 mm on the ZD611.
